92kW Diesel Hydraulic Power Unit - Atex Zone 2

92kW Diesel Hydraulic Power Unit - Atex Zone 2

Brimmond’s compact 92kW Diesel Driven HPU can be used either onshore or offshore to provide a hydraulic power solution for:
- Hydraulic spoolers/reelers
- Marine cranes
- Diver tooling
- Winches
- Casing tongs
- Hydraulic flushing

Engine Type	CAT 4.4TA
Starter	Jetstream ATEX air turbine starter
Engine Output	92kW @ 2200rpm
Pump Type	Main: 112cc Kawasaki variable displacement piston pump
Pump Output (max flow)	246lpm @ 190 bar
Pump Output (max pressure)	320 bar @ 150lpm
Filtration	90-micron suction, 3-micron pressure and 20-micron return (as standard, other available on request)
Oil Tank Capacity	450 litres
Oil Type	ISO 32 as standard, others on request
Hydraulic Connection	Quick release couplings (client specified type) Main Pump: • Pressure: 1” NPT Female • Return: 1 1/4” NPT Female • Case Drain: 3/4” NPT Female Auxiliary Pump: • Pressure: 3/4” NPT Female • Return: 1 NPT Female • Case Drain: 1/2” NPT Female
Fuel Type Capacity	225 litres
Control Panel	• Side mounted • Main pump load/unlaod • Auxiliary pump load/unload • Engine rpm • Main pump pressure • Auxiliary pump pressure • Exhaust temperature • Coolant temperature • Hydraulic oil temperature
Safety Features	• Fully enclosed unit • ESD switch • Low oil shutdown • High temp shutdown overspeed shut down • Pressure relief valves
Moving & Handling	• DNV 2.7-3, Type A, Class R45 • 4-leg certified sling set • Forklift pockets
Dimensions	3000mm (L) x 1580mm (W) x 2040mm (H)
Weight	Gross 6,000kg

- Datasheet - 92kW Diesel Hydraulic PU
